Waterproofing Guidelines for Residential and Small Projects ( Terrace - RCC - New )

Published by Hemant Chauhan in Waterproofing.

Terrace - RCC - New - After Minimum 28 days of curing of the Slab

Surface Preparation

  • Clear and thoroughly clean the surface with wire brush, electromechanical grinders and jute brush.
  • Ensure surface is totally dust-free by using a high speed air blower
  • Wash the surface with water to identify cracks
  • Mark the cracks with chalk to identify them properly
Repair of Crack
  • Use a grinder to widen the identified crack by 8 to 10mm, clear the cavity by jute brush or blower.
  • Use solvent free epoxy BS Epoxy system Part A & Part B mixed together in the fixed ratio and to be poured in the cracks to seal the cracks

Application of Cove or Gola along the parapet wall and terrace floor
  • Ensure wall plaster is complete and cured.
  • Apply a bond coat of BS Epoxy 611 2K system by brush just before making gola . cove  of 75mm
  • Make a mix of cement : sand: aggregate 5mm in ratio of 1: 1.5: 3, add 5% BS Smartbond 100 by weight of cement in the mix and make a cove or gola along the wall on a still wet bond coat of BS Epoxy 611 applied before.
  • Cure it for 3 days, by using jute cloth or water spray curing 3 times a day.
Application of Waterproofing Coating
a) Always Ensure before starting, the surface is dust free, use a high speed blower if possible or jute brush to remove any dust.
b) Type Cementitious 1 Part or 2 Parts
        1. Priming: Apply a coat of 2k waterborne epoxy primer  BS SmartPrime WB EP, Resin 1 Part, Hardener 2 Parts and Water 3 Parts, and apply by brush on the entire repaired and prepared surface.
        2. After a gap of 7 to 8 hours,
        • Applying the first coat of  Acrylic Cementitious System like MoistureZero Liquid chemical mixed with cement in 1:1 ratio
        • Start from a corner to allow application of  glass fiber mesh as reinforcement to the layer of waterproofing
        • Glass fiber mesh to overlap by 5cms and leveled properly
        • After 4 hours, apply the second and third layer of MoistureZero mixed with cement in a ratio of 1:1.5 to finish the layer.
        • On Wall / Vertical surface the application should be minimum 300mm above the gola/cove line
                     3.Cure for 3 days by jute sacks after 6 hours of final coat. After curing                    test waterproofing for 4 day by water ponding.

            Apply Protection Plaster of 8 to 10mmthickness, prepared using cement and sand in ratio of 1:4 admixed with BS smartbond 100 at 1.5% weight of cement and 6mm fiber to allow further built up of tiles etc to not damage the waterproofing.
