Vandex Super Cementitious Crystalline Waterproofing (25 kg) - Tremco

Vandex Super is a cementitious, ready-mixed, in-depth crystalline waterproofer based on grey Portland cement, specially treated quartz sand and a compound of active chemicals. When applied to a concrete surface, the active chemicals react with free lime and capillary moisture to form insoluble crystalline complexes that block capillaries and minor shrinkage cracks - creating a permanently active barrier against water ingress, even under positive or negative water pressure.

The treated concrete continues to "breathe" - water vapour can still pass through the structure - while liquid water, sea water, waste water and aggressive ground water are stopped. Approved for use in drinking water structures. Compliant with EN 1504-3 (Class R3, 25 MPa) as a CC fine mortar for non-structural concrete repair.

Primary Applications

• Foundations, slabs, basements and retaining walls
• Construction joints (horizontal and vertical)
• Sewage treatment plants and underground tanks
• Swimming pools and water-retaining structures
• Backfilled structural elements
• Drinking water tanks and reservoirs
• Active and passive waterproofing - positive or negative side

Key Features & Benefits

• Permanently active - re-seals new shrinkage cracks for the life of the structure
• Works under positive and negative water pressure
• Approved for potable / drinking water contact
• Resists sea water, waste water, aggressive ground water and many chemicals
• Allows the substrate to remain water-vapour permeable (concrete still breathes)
• Reaction to fire: Class A1 (non-combustible)
• Can be applied by brush, spray or dry-sprinkle & trowel
• Compliant with EN 1504-3 / CE-marked

Technical Properties

• Appearance: Grey powder
• Compressive strength: 25 MPa (Class R3)
• Adhesive bond: 0.8 MPa
• Modulus of elasticity: 20 GPa
• Capillary absorption: 0.5 kg/m²·h^0.5
• Chloride ion content: 0.05%
• Workability at 20 °C: approx. 30 min
• Setting time at 20 °C: 1–2 h
• Mixing ratio (by volume): 5 parts powder to ~2 parts water (25 kg + ~7–8.5 L)

Coverage

• Concrete slab - water pressure: 1.2 kg/m² (1 coat, dry sprinkle / brush / spray)
• Concrete slab - moisture only: 0.8 kg/m² (1 coat)
• Concrete walls - water pressure: 1.5 kg/m² (2 coats)
• Construction joints: 1.5 kg/m² (1 coat by brush)

Packaging & Shelf Life

Supplied in 25 kg PE-lined paper bags. Shelf life is 12 months when stored in a dry place in unopened, undamaged original packaging.

How to Use (Brief)

1. Substrate must be sound, even, open-pored and roughened. Remove all bitumen, oil, grease, paint and laitance. Stop active leaks first with VANDEX PLUG.
2. Pre-saturate the substrate so it is damp but not wet. Remove standing water on horizontal surfaces.
3. Mix 5 parts Vandex Super to ~2 parts water by volume in a clean container with a mechanical mixer for at least 3 minutes to a thick-paint consistency. Do not re-temper with water - only re-stir.
4. Apply by brush (cross-wise: vertical bottom-up, then horizontal), by spray with a fine-mortar spraying device (4 mm nozzle), or by dry sprinkle & power trowel onto fresh concrete at initial set.
5. Apply the second coat while the first is still surface-damp. Do not apply below +5 °C or to a frozen substrate.
6. Cure: Keep damp for at least 5 days. Protect from rain for 24 h, and from sun, wind and frost. Backfill after 3 days. Fill water-retaining structures only after surface treatment has hardened - typically not less than 14 days.

Manufactured by Vandex International Ltd, Switzerland. Distributed in India by Tremco CPG (India) Pvt. Ltd. Authorised distribution by Technotrade Associates - Pan-India delivery, dispatched within 3 working days after payment confirmation.
